brainstate documentation

brainstate implements a State-based transformation system for programming compilation.

---

Features

State-based Transformation

BrainState provides an intuitive interface to write State-based programs with powerful transformation capabilities.

Neural Network Support

BrainState implements a neural network module system for building and training ANNs/SNNs.

---

Installation

CPU

pip install -U brainstate[cpu]

GPU

pip install -U brainstate[cuda12]
pip install -U brainstate[cuda13]

TPU

pip install -U brainstate[tpu]

---

See also the ecosystem

brainstate is one part of our brain simulation ecosystem.

---

Quick Start

BrainState enables Pythonic State-based programming with automatic state management in JAX transformations. Here’s a complete example demonstrating the key concepts:

1. States vs Constants: Defining Dynamic Variables

import brainstate
import jax.numpy as jnp

# Dynamic variables are defined with State
# These will be automatically tracked and managed through transformations
state_var = brainstate.State(jnp.array([1.0, 2.0, 3.0]))
param = brainstate.ParamState(jnp.array([[1.0, 2.0], [3.0, 4.0], [5.0, 6.0]]))

# Regular Python variables are constants
# These remain fixed and are not tracked
learning_rate = 0.01
num_steps = 100

2. JIT Compilation with Automatic State Management

# Define a stateful computation
def step_forward(x):
    # Access state value
    y = state_var.value @ param.value
    # Update state in-place
    state_var.value = state_var.value + 0.1
    return y

# JIT compilation automatically handles state
step_jit = brainstate.transform.jit(step_forward)

# States are tracked and updated automatically!
result1 = step_jit(jnp.array(1.0))
result2 = step_jit(jnp.array(1.0))  # state_var has been updated

3. Gradient Computation with State Awareness

# Define a loss function with states
def loss_fn(x):
    pred = state_var.value @ param.value
    return jnp.sum((pred - x) ** 2)

# Compute gradients - only for ParamState, not all States!
grad_fn = brainstate.transform.grad(loss_fn, grad_states=param)

# Get gradients
target = jnp.array([1.0, 2.0])
grads = grad_fn(target)

# Update parameters
param.value = param.value - learning_rate * grads

4. Vectorization (vmap) with State Broadcasting

# Reset states for demo
state_var.value = jnp.array([1.0, 2.0, 3.0])

# Process batch of inputs with vmap
def process_single(x):
    return jnp.sum(state_var.value * x)

# vmap automatically broadcasts states across batch dimension
process_batch = brainstate.transform.vmap(
    process_single,
    in_axes=0,  # batch over first axis of input
    out_axes=0  # batch over first axis of output
)

# Process entire batch - state is shared/broadcasted
batch_inputs = jnp.array([[1., 2., 3.],
                          [4., 5., 6.],
                          [7., 8., 9.]])
batch_results = process_batch(batch_inputs)

5. Complete Training Loop Example

import brainstate as bst
import jax.numpy as jnp

# Define a simple model with states
class SimpleModel(brainstate.nn.Module):
    def __init__(self, in_size, out_size):
        super().__init__()
        self.weight = brainstate.ParamState(brainstate.random.randn(in_size, out_size) * 0.01)
        self.bias = brainstate.ParamState(jnp.zeros(out_size))

    def __call__(self, x):
        return x @ self.weight.value + self.bias.value

# Create model
model = SimpleModel(3, 2)

# Define loss with automatic state tracking
def loss_fn(x, y):
    pred = model(x)
    return jnp.mean((pred - y) ** 2)

# JIT + Grad: compose transformations seamlessly
params = model.states(brainstate.ParamState)

@brainstate.transform.jit
def train_step(x, y):
    # Compute gradients only for ParamStates
    grads = brainstate.transform.grad(loss_fn, grad_states=params)(x, y)

    # Update parameters
    for key in params.keys():
        params[key].value -= 0.01 * grads[key]

    return loss_fn(x, y)

# Training loop - states updated automatically!
for i in range(100):
    x_batch = brainstate.random.randn(32, 3)
    y_batch = brainstate.random.randn(32, 2)
    loss = train_step(x_batch, y_batch)
    if i % 20 == 0:
        print(f"Step {i}, Loss: {loss:.4f}")

Key Advantages:

• ✅ Intuitive: States behave like normal Python variables with .value

• ✅ Automatic: No manual state threading through transformations

• ✅ Composable: JIT, grad, vmap work together seamlessly

• ✅ Type-safe: Different state types (State, ParamState, RandomState) for different purposes

• ✅ Efficient: Zero-overhead state management compiled by JAX
