Biologically Detailed Brain Cell Modeling#
braincell is a Python library for biophysically detailed neuron modeling,
from single-compartment Hodgkin–Huxley cells to fully morphological
multi-compartment reconstructions with realistic dendrites and axons.
It is built on JAX and brainstate, so every model is differentiable, JIT-compiled, and runs unchanged on CPU, GPU, and TPU.
Install braincell and simulate your first neuron in a few minutes.
The mental model behind cells, mechanisms, morphology, discretization, and integration.
Step-by-step notebooks for single- and multi-compartment models.
Choose, compose, and write the solvers that advance your equations.
Load morphologies from SWC, ASC, NeuroML2, and NeuroMorpho.Org.
The complete public API: classes, functions, channels, and ions.
What is braincell?#
braincell lets you describe a neuron the way a neuroscientist thinks about
one — geometry, ion channels, ion species, and stimuli — and then turns that
description into a fast, differentiable simulation. Its design goals are:
Biophysical precision. Model neural dynamics across scales, from single ion-channel gating to morphologically detailed dendritic computation.
Stiff-system performance. A registry of numerical solvers (
braincell.quad) — explicit, implicit, exponential-Euler, and staggered cable solvers — handles the stiff dynamics of biophysical neurons efficiently.Differentiability. Because everything runs on JAX, gradients flow through whole simulations, enabling gradient-based fitting and optimization.
One canonical API. Mechanisms are declared with explicit physical units and painted or placed onto a cell, keeping declaration cleanly separated from the runtime that executes it.
Feature highlights#
Capability |
What you get |
|---|---|
Single-compartment neurons |
|
Multi-compartment cells |
|
Morphology system |
|
File-format readers |
SWC, Neurolucida ASC, and NeuroML2 readers, plus a full NeuroMorpho.Org client with caching. |
Visualization |
|
Numerical integration |
|
Declarative mechanisms |
|
A first taste#
A single-compartment thalamic relay (HTC) neuron, assembled from ion species and channels:
import braincell
import braintools
import brainunit as u
class HTC(braincell.SingleCompartment):
def __init__(self, size, solver: str = 'ind_exp_euler'):
super().__init__(size, V_initializer=braintools.init.Constant(-65. * u.mV),
V_th=20. * u.mV, solver=solver)
self.na = braincell.ion.SodiumFixed(size, E=50. * u.mV)
self.na.add(INa=braincell.channel.Na_Ba2002(size, V_sh=-30 * u.mV))
self.k = braincell.ion.PotassiumFixed(size, E=-90. * u.mV)
self.k.add(IDR=braincell.channel.KDR_Ba2002(size, V_sh=-30. * u.mV))
self.ca = braincell.ion.CalciumDetailed(size, C_rest=5e-5 * u.mM, tau=10. * u.ms, d=0.5 * u.um)
self.ca.add(ICaL=braincell.channel.CaL_IS2008(size, g_max=0.5 * (u.mS / u.cm ** 2)))
self.Ih = braincell.channel.HCN_HM1992(size, g_max=0.01 * (u.mS / u.cm ** 2), E=-43 * u.mV)
self.IL = braincell.channel.IL(size, g_max=0.0075 * (u.mS / u.cm ** 2), E=-70 * u.mV)
See First Steps to run this model and plot a spike train, or Architecture to understand each piece.
How this documentation is organized#
The docs are layered by what you are trying to do:
Get Started — install the package and run a first model. Start here if you are new.
Concepts — the design and vocabulary of
braincell: cells, mechanisms, morphology, discretization, and integration. Read this to build a mental model before diving deep.Modeling guides — task-focused tutorials and runnable examples for single- and multi-compartment models, and for numerical integration.
File Formats & IO — how to load and save morphologies.
Developer Guide — project layout, testing, and how to extend the library.
API Reference — the exhaustive, generated reference for every public symbol.
Ecosystem#
braincell is one part of the BrainX brain-modeling ecosystem. If you use it in your research, please cite
it via its Zenodo DOI.
