The Composable API#

Every functional generator has a class counterpart (Step, Sinusoidal, OUProcess, …). Instead of an array, the class returns an Input object: a description of a signal that produces its array when called. Objects can be combined into new objects, which makes protocols easy to build from parts.

Operation

Result

a + b, a - b, a * b, a / b

pointwise arithmetic; b may also be a number or quantity

-a

negation

a & b

a followed by b in time (Sequential(a, b))

`a

b`

a.scale(k), a.clip(lo, hi), a.apply(f)

transform the values

a.shift(t)

delay (or advance, for negative t) within the same duration

a.smooth(tau)

first-order low-pass filter with time constant tau

a.repeat(n)

a played n times in a row

1. Setup#

import brainstate
import brainunit as u
import matplotlib.pyplot as plt
import numpy as np

import braintools.input as inp

brainstate.environ.set(dt=0.1 * u.ms)
dt_ms = 0.1


def t_of(x):
    return np.arange(len(x)) * dt_ms


def show(panels, ncols=2, height=2.2):
    nrows = int(np.ceil(len(panels) / ncols))
    fig, axes = plt.subplots(nrows, ncols, figsize=(6 * ncols, height * nrows), squeeze=False)
    for ax, (title, x) in zip(axes.flat, panels.items()):
        ax.plot(t_of(x), u.get_mantissa(x), lw=1)
        ax.set_title(title, fontsize=10)
    for ax in axes.flat[len(panels):]:
        ax.axis("off")
    for ax in axes[-1]:
        ax.set_xlabel("time (ms)")
    fig.tight_layout()
    plt.show()

2. Objects, Arrays, and Caching#

Calling an Input generates its array once and caches it; later calls return the same array. For stochastic inputs this means one object always yields the same realization until you ask for a new one with recompute=True. Use separate objects (with different seeds) when you need independent noise.

noise = inp.OUProcess(mean=0.0, sigma=1.0, tau=5 * u.ms, duration=100 * u.ms)
first = noise()
print("second call returns the cached array:", bool(u.math.all(first == noise())))
print("recompute=True draws a new one:     ", not bool(u.math.all(first == noise(recompute=True))))

# The same object used twice is perfectly correlated with itself:
doubled = noise + noise
print("noise + noise == 2 * noise:", bool(u.math.allclose(doubled(), 2 * noise())))
independent = inp.OUProcess(0.0, 1.0, 5 * u.ms, 5000 * u.ms, seed=1) + inp.OUProcess(0.0, 1.0, 5 * u.ms, 5000 * u.ms, seed=2)
print(f"std of two independent processes summed: {float(np.std(independent())):.2f} (about sqrt(2))")
second call returns the cached array: True
recompute=True draws a new one:      True
noise + noise == 2 * noise: True
std of two independent processes summed: 1.47 (about sqrt(2))

3. Arithmetic#

Arithmetic combines two inputs sample by sample; numbers and quantities are treated as constant inputs. If the operands have different durations, the shorter one is padded with zeros. Two details to keep in mind:

  • Division treats zeros in the divisor as 1 (in the divisor’s unit) instead of producing inf; with a dimensionless divisor this keeps the numerator. This also covers the zero padding of a shorter divisor.

  • Units follow the usual rules: nA + pA is converted, nA * dimensionless stays in nA, nA + mV raises an error.

carrier = inp.Sinusoidal(1.0 * u.nA, 40 * u.Hz, 300 * u.ms)
envelope = inp.GaussianPulse(1.0, center=150 * u.ms, sigma=40 * u.ms, duration=300 * u.ms)
offset = inp.Constant([(0.5 * u.nA, 300 * u.ms)])

modulated = carrier * envelope + offset
print(f"unit: {u.get_unit(modulated())}, peak {float(modulated().max().to_decimal(u.nA)):.3f} nA (1 + 0.5)")

short = inp.Constant([(1.0, 100 * u.ms)])
long = inp.Constant([(1.0, 300 * u.ms)])
padded = (short + long)()
print(f"short + long: {padded.shape[0]} samples; value 2 in the first 100 ms, then {float(padded[-1])}")

ratio = (inp.Constant([(3.0, 10 * u.ms)]) / inp.Constant([(0.0, 10 * u.ms)]))()
print(f"3 / 0 -> {float(ratio[0])} (numerator kept)")
conductance = (inp.Constant([(3.0 * u.nA, 10 * u.ms)]) / inp.Constant([(2.0 * u.mV, 10 * u.ms)]))()
print(f"3 nA / 2 mV -> {conductance[0]}")

show({"Sinusoid(40 Hz) * GaussianPulse + 0.5 nA": modulated()}, ncols=1)
unit: nA, peak 1.488 nA (1 + 0.5)
short + long: 3000 samples; value 2 in the first 100 ms, then 1.0
3 / 0 -> 3.0 (numerator kept)
3 nA / 2 mV -> 1.5 uS
../_images/c3574360f036e9c77b537d7af0fe1b60b9b08032bc7de492211ca5183d5030c1.png

4. Combining in Time: & and |#

a & b plays b after a, so durations add. This is the natural way to write a protocol as a list of phases. a | b keeps the larger of the two values at every sample.

baseline = inp.Constant([(0.0 * u.nA, 100 * u.ms)])
ramp_up = inp.Ramp(0.0 * u.nA, 0.4 * u.nA, 200 * u.ms)
hold = inp.Constant([(0.4 * u.nA, 200 * u.ms)]) + inp.OUProcess(0.0 * u.nA, 0.03 * u.nA, 5 * u.ms, 200 * u.ms, seed=0)
ramp_down = inp.Ramp(0.4 * u.nA, 0.0 * u.nA, 100 * u.ms)

protocol = baseline & ramp_up & hold & ramp_down
print(f"total duration {protocol.duration}, {protocol().shape[0]} samples")

a = inp.Step([0.0, 1.0, 0.0], [0, 50, 150] * u.ms, 300 * u.ms)
b = inp.Step([0.0, 0.6, 0.0], [0, 100, 250] * u.ms, 300 * u.ms)
show({"baseline & ramp & noisy hold & ramp": protocol(), "a | b (pointwise maximum)": (a | b)()})
total duration 600 ms, 6000 samples
../_images/0481d62f82cefe77a3afd13c182aea2973f0b1340191cb8b9e297507899f66ad.png

5. Transformations#

  • scale(k) multiplies by k; clip(lo, hi) bounds the values (either bound may be None); apply(f) applies any function to the generated array.

  • shift(t) moves the signal by t within the same duration: a delay inserts zeros at the start and drops the end, an advance does the opposite.

  • smooth(tau) is the first-order low-pass \(y_i = y_{i-1} + \frac{dt}{\tau}(x_i - y_{i-1})\), so a unit step reaches \(1 - e^{-1} \approx 0.632\) about tau after it starts.

  • repeat(n) concatenates n copies.

pulse = inp.Step([0.0, 1.0, 0.0], [0, 20, 60] * u.ms, 100 * u.ms)

delayed = pulse.shift(30 * u.ms)()
on = np.flatnonzero(np.asarray(delayed)) * dt_ms
print(f"shift(30 ms): pulse now from {on[0]:.0f} to {on[-1] + dt_ms:.0f} ms, length still {delayed.shape[0]} samples")

smoothed = pulse.smooth(10 * u.ms)()
print(f"smooth(10 ms) at 10 ms after the step: {float(smoothed[300]):.3f} (1 - exp(-1) = {1 - np.exp(-1):.3f})")

wave = inp.Sinusoidal(1.0, 10 * u.Hz, 100 * u.ms)
rectified = wave.clip(0.0, None)
squared = wave.apply(lambda x: x ** 2)
print(f"clip(0, None) min {float(rectified().min()):.2f}; apply(x**2) mean {float(squared().mean()):.3f} (0.5)")
print(f"repeat(3): {pulse.repeat(3)().shape[0]} samples")

show({"pulse": pulse(), "pulse.shift(30 ms)": delayed, "pulse.smooth(10 ms)": smoothed,
      "pulse.repeat(3)": pulse.repeat(3)()})
shift(30 ms): pulse now from 50 to 90 ms, length still 1000 samples
smooth(10 ms) at 10 ms after the step: 0.638 (1 - exp(-1) = 0.632)
clip(0, None) min 0.00; apply(x**2) mean 0.500 (0.5)
repeat(3): 3000 samples
../_images/64b6e9991852c37b41620d9422e2d370d7af0e5a4e4434202689cae3daf27837.png

6. Multiple Channels#

Stochastic inputs accept n for independent channels and return shape (steps, n). A single-channel input combines with a multi-channel one by broadcasting over the channels, for example to add a common stimulus to independent noise:

common = inp.Step([0.0, 0.5, 0.0] * u.nA, [0, 50, 150] * u.ms, 200 * u.ms)
private = inp.OUProcess(0.0 * u.nA, 0.1 * u.nA, 10 * u.ms, 200 * u.ms, n=5, seed=0)
drive = (common + private)()
print(f"common {common().shape} + private {private().shape} -> {drive.shape}")

fig, ax = plt.subplots(figsize=(8, 2.8))
ax.plot(t_of(drive), drive.to_decimal(u.nA), lw=0.8)
ax.set_xlabel("time (ms)")
ax.set_ylabel("nA")
plt.show()
common (2000,) + private (2000, 5) -> (2000, 5)
../_images/7fd5114c8032e0da668650be142a7a3c6cb51434957f483c4a951a7f0678dc1b.png

7. Families of Protocols#

Because inputs are objects, a family of protocols is just a list built in a loop or comprehension. Here are the current steps of an F-I (frequency-current) experiment, driving the leaky integrate-and-fire neuron from the introduction (vectorized over all amplitudes at once).

amplitudes = np.linspace(0.0, 0.6, 13) * u.nA
family = [inp.Constant([(0 * u.nA, 50 * u.ms), (a, 500 * u.ms), (0 * u.nA, 50 * u.ms)]) for a in amplitudes]
I = u.math.stack([f() for f in family], axis=1)  # (steps, 13)

tau, R, E_L, V_th = 20 * u.ms, 100 * u.Mohm, -70 * u.mV, -50 * u.mV
dt = brainstate.environ.get_dt()
V = u.math.full(I.shape[1], -70.0) * u.mV
counts = np.zeros(I.shape[1], dtype=int)
for I_t in I:
    V = V + dt / tau * (-(V - E_L) + R * I_t)
    fired = np.asarray(V >= V_th)
    counts += fired
    V = u.math.where(fired, E_L, V)
rate = counts / 0.5  # spikes per second during the 500 ms step

rheobase = (V_th - E_L) / R
fig, ax = plt.subplots(figsize=(5, 3))
ax.plot(amplitudes.to_decimal(u.nA), rate, "o-")
ax.axvline(rheobase.to_decimal(u.nA), ls="--", color="0.5", label=f"rheobase (V_th - E_L) / R = {rheobase.to_decimal(u.nA):.2f} nA")
ax.set_xlabel("step amplitude (nA)")
ax.set_ylabel("rate (Hz)")
ax.legend(fontsize=8)
plt.show()
print("first amplitude that fires:", amplitudes[np.argmax(rate > 0)])
../_images/4f5a1f3d77e7b5d50b25b7a9d8ae6de6443c383b52e4c34462197610d711290e.png
first amplitude that fires: 0.25 nA

Summary#

  • Composable classes return Input objects; calling one generates and caches its array (recompute=True redraws stochastic inputs).

  • Reusing the same stochastic object reuses the same noise; create separate objects for independent noise.

  • + - * / combine sample by sample with zero padding; division treats a zero divisor as 1.

  • & concatenates in time, | takes the maximum; shift keeps the duration; smooth(tau) is a first-order low-pass.

  • Single-channel inputs broadcast over multi-channel ones.
