Hopf Oscillator

The Hopf (Stuart-Landau normal-form) oscillator is the canonical model of rhythm onset. Each node obeys the supercritical Hopf normal form

\[\dot x = (a - x^2 - y^2)\,x - \omega\,y,\qquad \dot y = (a - x^2 - y^2)\,y + \omega\,x,\]

where the bifurcation parameter \(a\) controls the regime: for \(a<0\) the origin is a stable fixed point (the node is silent), while for \(a>0\) a stable limit cycle of radius \(\sqrt{a}\) appears and the node oscillates at angular frequency \(\omega\). It is the workhorse phenomenological node for whole-brain resting-state models.

Reference: Deco, Kringelbach, Jirsa & Ritter (2017), The dynamics of resting fluctuations in the brain, Scientific Reports 7:3095.

Build the model

We pick a = 0.25 > 0 so the node sits on a limit cycle.

node = brainmass.HopfStep(in_size=1, a=0.25, w=0.3)
node

HopfStep(
  in_size=(1,),
  out_size=(1,),
  init_x=Constant(value=0.0),
  init_y=Constant(value=0.0),
  method=exp_euler,
  a=Const(
    fit=False,
    t=IdentityT(),
    reg=None,
    val=Array(0.25, dtype=float32)
  ),
  w=Const(
    fit=False,
    t=IdentityT(),
    reg=None,
    val=Array(0.3, dtype=float32)
  ),
  beta=Const(
    fit=False,
    t=IdentityT(),
    reg=None,
    val=Array(1., dtype=float32)
  )
)

Run a simulation

The high-level Simulator compiles the whole rollout into one XLA program — no hand-rolled Python loop. We discard a short transient.

sim = brainmass.Simulator(node, dt=0.1 * u.ms)
res = sim.run(200. * u.ms, monitors=['x', 'y'], transient=20. * u.ms)
res['x'].shape, res['ts'][-1]

((1800, 1), Quantity(200., "ms"))

Visualize

The timeseries shows the sustained oscillation; the phase portrait shows the trajectory settling onto the circular limit cycle of radius \(\sqrt{a} = 0.5\).

fig, axes = plt.subplots(1, 2, figsize=(10, 4))
brainmass.viz.plot_timeseries(res['x'], ts=res['ts'], ax=axes[0])
axes[0].set_title('Hopf limit cycle (x)')
brainmass.viz.plot_phase_portrait(res['x'], res['y'], ax=axes[1])
axes[1].set_title('Phase portrait')
plt.tight_layout()
plt.show()

Try it: cross the bifurcation

Sweep the bifurcation parameter a across zero, giving each node a small kick off the fixed point. For a <= 0 the node decays back to silence; for a > 0 the settled amplitude grows as \(\sqrt{a}\).

for a in [-0.2, 0.0, 0.25, 1.0]:
    m = brainmass.HopfStep(in_size=1, a=a, w=0.3)
    brainstate.nn.init_all_states(m)
    m.x.value = m.x.value + 0.1  # small kick off the fixed point
    r = brainmass.Simulator(m, dt=0.1 * u.ms).run(
        300. * u.ms, monitors=['x'], transient=150. * u.ms, init_states=False)
    amp = float(np.sqrt(np.mean(u.get_magnitude(r['x']) ** 2)) * np.sqrt(2))
    print(f'a = {a:+.2f}  ->  settled amplitude = {amp:.3f}  '
          f'(sqrt(a) = {np.sqrt(max(a, 0)):.3f})')

a = -0.20  ->  settled amplitude = 0.000  (sqrt(a) = 0.000)
a = +0.00  ->  settled amplitude = 0.069  (sqrt(a) = 0.000)

a = +0.25  ->  settled amplitude = 0.502  (sqrt(a) = 0.500)
a = +1.00  ->  settled amplitude = 1.001  (sqrt(a) = 1.000)
